The peristaltic pump filling machine is easy to maintain.
Published time:
2025-03-04
The peristaltic filling machine consists of a filling system composed of a main drive system, a bottle feeding system, a pump head assembly, and a filling distribution assembly;
Maintenance of filling peristaltic pump is convenient and simple
Maintenance of Filling Peristaltic Pump is Convenient and Simple
The filling peristaltic pump consists of a filling system composed of a main drive system, a bottle feeding system, a pump head assembly, and a filling distribution assembly; a plugging system composed of a plug supply assembly and a plug pressure assembly; and an electrical control system. The structure is novel and reasonable.
The filling peristaltic pump consists of a filling system consisting of a main drive system, a bottle feeding system, a pump head group and a filling distribution group, a plug system consisting of a plug supply group and a plug pressure group, and an electrical control system. Its structure is novel and reasonable.
The filling peristaltic pump uses a peristaltic pump as its pump source, fully utilizing the peristaltic pump's characteristics of simple structure and no contact between the pump body and the liquid, eliminating the need for cleaning and disinfection of the pump body. Driven by a stepping motor or servo motor and controlled by a PLC, it allows for convenient adjustment of filling volume by simply inputting the corresponding number. The filling volume can be adjusted at any time during operation, with an accuracy of ±2%. It features a modular structure, with each unit having 4 channels and expandable to 4 units (16 channels) sharing a single controller.
The pump source of filling peristaltic pump adopts peristaltic pump. It makes full use of the characteristics of peristaltic pump. It has simple structure and no contact with medicine liquid. Therefore, it is not necessary to clean and disinfect the pump body. The filling peristaltic pump is driven by stepping motor or servo motor. It is easy to adjust the filling quantity by PLC control. It can adjust at any time in working state by inputting corresponding numbers. The precision can reach (+2%) by modular structure. Each unit has four channels and can be extended to four units (16 channels) with a common controller.
Advantages of the filling peristaltic pump:
Advantages of filling peristaltic pump:
1. Pollution-free: The fluid only contacts the pump tube, not the pump body.
1. Pollution-free: Fluid only contacts the pump pipe, not the pump body.
2. High accuracy: high repeatability and stability accuracy
2. High accuracy: repetitive accuracy, high stability accuracy
3. Low shear force: It is an ideal tool for transporting shear-sensitive and highly corrosive fluids.
3. Low shear force: an ideal tool for transporting shear-sensitive and erosive fluids
4. Good sealing: It has good self-priming ability, can idle, and can prevent backflow.
4. Good sealing performance: good self-priming ability, idle rotation, can prevent reflux
5. Simple peristaltic pump maintenance: No valves or seals; the tubing is the only consumable part.
5. Peristaltic pump maintenance is simple: no valves and seals, hoses are * vulnerable parts
6. Can pump liquids, gases, solids, or multiphase mixtures.
6. Pumpable liquid, gas, solid or multiphase mixtures
Application scope of the filling peristaltic pump:
Scope of application of filling peristaltic pump:
Filling peristaltic pumps can fill a wide range of liquids, including those with high viscosity, such as various pharmaceuticals, chemicals, oils, cosmetics, and food (excluding particulate liquids). The high filling accuracy makes it suitable for laboratory use.
Filling peristaltic pumps can fill a wide range of liquids, including liquids with high viscosity. Such as: all kinds of medicines, chemicals, oils, cosmetics, food and other non-granular liquids; high filling accuracy, suitable for laboratory use.
