GR2-1B Pro Dual-Channel Filling Machine
Category:
Tags:
- Product Description
GR2-1B Pro Dual-Channel Filling Machine
-
- Commodity name: GR2-1B Pro Dual-Channel Filling Machine
Flow range: 0–2400 ml/min (per channel); Filling volume range: 0.1–30,000 mL (per channel)
Product Introduction
◆ Dual-channel independent speed control allows for consistent filling volumes across both channels and enables proportional filling.
◆ Flow range: 0–2400 ml/min (per channel)
◆ Filling volume range: 0.1–30,000 mL (per channel)
◆ Precise and timed quantitative filling, ensuring high-accuracy liquid dispensing with a filling accuracy of up to ±1%.
◆ Adopting peristaltic pump filling technology, driven by a 57-step stepper motor with 128-fold microstepping control, this system delivers low vibration and high precision. Importantly, the liquid flows solely through tubing without coming into contact with the pump body, effectively minimizing the risk of secondary liquid contamination.
◆ Can be used to fill beverages, alcoholic drinks, daily chemical products, edible oils, soy milk, adhesives, nail polish, pharmaceutical solutions, pesticides, and other liquids—including those with certain viscosity or containing impurities.
◆ Preparation for medium dispensing, as well as the dispensing of other chemical reagents, can be carried out.
◆ Imported potentiometers regulate the flow rate.
◆ Three working modes are available: manual filling, automatic filling, and preset filling.
◆ Filling operation time setting, interval time setting, filling cycle count accumulation, and presetting
◆ Foot Pedal Switch Control
◆ 304 Stainless Steel Filling Nozzle
◆ Wide-range power supply, AC 90–260V, 50Hz/60Hz
Technical Specifications
Product Model GR2-1B Pro Number of Filling Nozzles 2 Electric motor Dual stepper motors driven independently Filling liquid volume setting range 0.1–30,000 mL (per channel) Traffic Range 0-2400mL/min Traffic Regulation Two channels with individually adjustable flow rates Rotational Speed Display 1-600rpm Filling Mode Three working modes are available: manual filling, automatic filling, and preset filling. Display Function 4-digit LED display for filling operation time, 4-digit LED display for filling interval time, and 5-digit LED display for filling count. Filling Time Setting Set range: 0.01 seconds to 999.9 seconds Interval Time Setting Set range: 0.01 seconds to 999.9 seconds Number of fillings Displayed 59,999 times Filling Cycle Setting Two modes are available: cumulative count and preset count. Method of Operation Membrane button control offers convenience, speed, and reliability; imported potentiometer knobs allow for precise flow adjustment. Power-loss memory function After power is restored, the parameters will remain in their pre-power-off state. Simply press the start button (or activate the foot switch) to resume operation using the previously set parameters. Foot Pedal Switch Control Standard foot pedal switch controls start and stop. Filling Bracket Standard filling bracket equipped, adjustable in height and length directions. Filling nozzle 304 stainless steel nozzle, standard configuration includes 2 nozzles with a 6mm inner diameter; 3mm and 4mm options are available. Power Consumption <120W Applicable Power Supply Wide-range voltage AC 90-260V, 50Hz/60Hz Work Environment 0-40°C, with humidity below 80% to prevent condensation. Dimensions 630mm × 255mm × 150mm (excluding the filling bracket) Weight 12KG Protection Level IP31 Dimensions
