S100-1B+JZ15C

Flow range: 0.047-45.32mL/min, dual-channel synchronous fluid delivery, inter-channel accuracy error ≤ ±3%

Category:

Tags:

S100-1B+JZ15C

Flow range: 0.047-45.32mL/min, dual-channel synchronous fluid delivery, inter-channel accuracy error ≤ ±3%

◆ Flow Range: 0.047-45.32mL/min
◆ Dual-channel synchronous fluid delivery, accuracy error between channels ≤ ±3%

◆ 42 stepper motor drive, split structure

◆ Speed Range: ≤100rpm

◆ 15-digit BCD DIP switch speed control, or external control signal speed control

◆ Switch quantity control start and stop, switch quantity control forward and reverse

◆ Flow accuracy up to ±1%
◆ Suitable for various specifications of tubing

◆ 24V DC power supply, optional power adapter, enabling 220V AC power supply

Product Model	S100-1B+JZ15C
Applicable Pump Head	JZ15C
Start/Stop Control	Can control start and stop
Direction Control	Reversible
Internal Speed Control	BCD DIP switch adjustment
External Speed Control	0-10kHz pulse control or 0-5V, 0-10V, 4-20mA analog signal control, optional, standard 0-10KHz
Internal Speed Range	1-100rpm, 15-speed adjustment, standard configuration is 5,10,15,20,25,30,35,40,45,50,60,70,80,90,100rpm, customizable
External Speed Range	0-100rpm, speed resolution 0.1rpm, full-range linear correspondence
Communication Control	RS485 communication control, using Modbus communication protocol, communication control and other external control cannot coexist, choose one
Speed Error	≤±0.5%
Adaptable Tubing	13#,14#,19#,16#
Start/Stop Control	Start/Stop Control Switch quantity control Normally Open, peristaltic pump running; Normally Closed (port 5 and port 7 shorted), peristaltic pump stops
Direction Control	Direction Control Switch quantity control Normally Open, peristaltic pump clockwise; Normally Closed (port 6 and port 7 shorted), peristaltic pump counterclockwise
Applicable Power Supply	11.4-25.2V DC; or 100-240V AC (optional power adapter) 50/60Hz
Operating Environment	0-40℃, Relative Humidity: <80%
Weight	600g
